SY16C
1.75 Tonne Excavators
The SANY SY16C is extremely powerful and demonstrates outstanding stability in all situations. This machine meets all the expectations of its users thanks to having a robust design and being easy to service.

  • Rated Power
    14.6kW/2400rpm
  • Operating Weight
    1,750kg
  • Dig Depth
    2,360mm
Specifications
Technical data
Overall length 3575mm
Overall width 1350 mm
Overall height 2420 mm
Upper width 980 mm
Platfrom height 470mm
Track length 1858 mm
Track gauge 1120 mm
Track ground length 1125 mm
Tail swing radius 920 mm
Ground contact length of the track  3,445 mm
Track shoe width 230 mm

Boom length 1810 mm
Bucket arm length 1130 mm
Bucket capacity 0.04 m³

WEIGHT
Total weight 1920 kg

WORKING RANGE
Max. digging height 3665 mm
Max. unloading height 2635 mm
Max. digging depth 2360 mm
Max. digging distance 4000 mm
Min. slewing radius 1655 mm
Max. height at min. slewing radius 2745 mm


ENGINE
Model Yanmar/3TNV70
Rated power 10.3 kW/2200rpm
Max. torque 47.6 Nm
Travel speed 2.1\3.7 km/h

OUTPUT
Slewing speed 9rpm
Fuel tank 23L
Engine coolant 3.8L
Engine oil 2.0L
Hydraulic oil tank 21L
Benefits & Features

Quiet and low-vibration engine
+ Efficient, powerful load-sensing hydraulic system
+  Responsive, precise control
+ Ergonomic, comfortable seat
+ Clear instruments and large, high-resolution colour display
+ Optimum visibility
+ Powerful heating
+ Standard connections for commercially available accessories
+ Low weight and compact dimensions
+ All cladding elements made of metal
+ All important maintenance points are very easily accessible
+ ROPS/FOPS-certified for safety in operation
