| Technical data | |
| Overall length | 11100 mm |
| Overall width | 3190 mm |
| Overall height | 3145 mm |
| Upper width | 3085mm |
| Track length | 4445 mm |
| Track gauge | 2590 mm |
| Tail swing radius | 3300 mm |
| Min.Ground Clearance | 550 mm |
| Track shoe width | 600 mm |
| Boom length | 6470 mm |
| Bucket arm length | 3200 mm |
| Bucket capacity | 1.5 m³ |
| WEIGHT | |
| Total weight | 34300 kg |
| WORKING RANGE | |
| Max. digging height | 10100 mm |
| Max. digging depth | 7410 mm |
| Max. digging distance | 11050 mm |
| Min. slewing radius | 4450 mm |
| Max. height at min. slewing radius | 8500 mm |
| ENGINE | |
| Model | Isuzu/AA-6HK1XQP-01 |
| Rated power | 190.5 kW/2000rpm |
| Travel speed | 3.4\5.4 km/h |
| OUTPUT | |
| Slewing speed | 10.6rpm |
| Fuel tank | 475L |
| Engine coolant | 31L |
| Engine oil | 29L |
| Hydraulic oil tank | 239L |
High Efficiency & Low Consumption
Isuzu Engine Customized for SANY
With a dual-pump, dual-circuit constant power control system, the Isuzu engine outputs a continuously strong operating force. Optimized performance of the engine reduces power loss.
Auto Deceleration System
Auto deceleration of SY335C 33.5 ton excavator reduces fuel consumption by 5-10%. When an operation stops for 3.5 seconds, the engine speed drops automatically to idle level and maintains the idling state.
Multiple Working Modes
Four working modes are displayed for your different requirements at various jobsites. Heavy-duty mode maximizes the operating efficiency, standard mode reduces fuel consumption and noise, light-duty mode is economical with lower fuel consumption, and breaker mode specially designed for hammer operation.
Safe and Comfortable Cab
Innovative Large Cab
Large windows provide a wide view of surroundings. The control levers and joysticks designed and arranged according to human engineering are all within the reach of operator. They can be operated easily with little strength.
Air-conditioner with Multiple Air Outlets
High quality automatic air conditioner provides better cooling effect. There are several air outlets–the front window defrost outlet protects visibility, and the outlets for operator face, back, and feet can be turned on/off as desired.
Silicone Rubber Shock Absorber
The operator station is supported with innovative silicone rubber shock absorber. This shock absorber is fixed to the swing platform in six points, which minimizes the shock brought by impact, considerably increasing cab stability and improving operator comfort.
High Reliability
Falling Object Protection Structure
The top plate of cab is punch-formed with thick high-strength steel sheet integrated with toughened glass door and windows which maximize the safety of operator.
Anti-swing Valve & Delay Valve
Making the swing operation more stable and reliable, swing brake ensures the safety of machine while stopping.
Large-capacity Fuel Tank with Anti-rust Treatment
Interior of the fuel tank has been treated well against rusting. No rusting will occur even if the tank is soaked in oil containing water and phosphoric acid and other chemicals for a long period of time.
