| Technical data | |
| Overall length | 11700 mm |
| Overall width | 3360 mm |
| Overall height | 3980 mm |
| Upper width | 3290mm |
| Track length | 5440 mm |
| Track gauge | 2740 mm |
| Tail swing radius | 3765 mm |
| Min.Ground Clearance | 1220 mm |
| Track shoe width | 600 mm |
| Boom length | 7000 mm |
| Bucket arm length | 3000 mm |
| Bucket capacity | 2.2 m³ |
| WEIGHT | |
| Total weight | 49500 kg |
| WORKING RANGE | |
| Max. digging height | 10120 mm |
| Max. digging depth | 6600 mm |
| Max. digging distance | 10850 mm |
| Min. slewing radius | 5130 mm |
| Max. height at min. slewing radius | 8800 mm |
| ENGINE | |
| Model | Isuzu 6WG1XKSC-01 |
| Rated power | 300 kW/1800rpm |
| Travel speed | 3.1\5.4 km/h |
| OUTPUT | |
| Slewing speed | 8rpm |
| Fuel tank | 680L |
| Engine coolant | 24L |
| Engine oil | 50L |
| Hydraulic oil tank | 480L |
Super power
Imported Isuzu engine. Rated power is up to 300kw.
Strong adaptability
With fuel tank self-filtration system and fuel – level filter system, to ensure cleanliness of each drop fuel. In this way, the fuel adaptability is higher.
Control system with independent intellectual property
Optimizing power matching, adaptability of high temperature, heavy load and highland. Less fuel consumption for same operation case.
Independent heat dissipation system
Ensure the optimum temperature of hydraulic system under the condition of high temperature and heavy load.
Design for mine
Ensure the reliability of key structure under heavy load condition. Main structures are all used finite element analysis, IIW International standard/AISC Japanese standard are adopted. Design is more reliable. Adopting comprehensive test and verification system for whole machine and every part, the reliable of machine is much higher.
