| Technical data | |
| Overall length | 5930mm |
| Overall width | 2000 mm |
| Overall height | 2600 mm |
| Upper width | 1860mm |
| Track length | 2545 mm |
| Track gauge | 1600 mm |
| Tail swing radius | 16400 mm |
| Min.Ground Clearance | 330 mm |
| Track shoe width | 400 mm |
| Boom length | 3000 mm |
| Bucket arm length | 1550 mm |
| Bucket capacity | 0.21 m³ |
| WEIGHT | |
| Total weight | 5780 kg |
| WORKING RANGE | |
| Max. digging height | 5690 mm |
| Max. unloading height | 3930 mm |
| Max. digging depth | 3815 mm |
| Max. digging distance | 6090 mm |
| Min. slewing radius | 2555 mm |
| Max. height at min. slewing radius | 4495 mm |
| ENGINE | |
| Model | Isuzu 4JG1 |
| Rated power | 36 kW/2100rpm |
| Max. torque | 47.6 Nm |
| Travel speed | 2.4\4.47 km/h |
High efficiency and reliability
The customized Isuzu 4JG1 Engine with Tier 3 emission standard shows extra-strong working power, ensuring the high reliability especially in the tough working environment.
The strengthened bucket uses wearing-resisting steel plate in its bottom, and the optimized arc shape reduces the digging resistance and abrasion caused by the rocks.
With the unique AOCT Self-optimizing control technology and new hydraulic system, the output power of engine can be fully used. Movement is more quickly, working more durable.
High Reliability and Stability
Equipped with reinforced attachment and X-shape undercarriage, the machine’s performance is more reliable, the life of structure is improved by 10%.
Comfortable operation and easy maintenance
The spacious view and suspension seat design, together with the damping and noise-reduction performance, gives the operator more confortable experience.
The large covering parts makes the maintenance more easily and approachable.
Energy efficient and Environmentally Friendly
Environmentally friendly engine, equipped with new controller, the fuel combust more sufficiently. The fuel consumption is 8% lower than last generation in the same efficiency.
